Adapter compatible with the Lehnhoff system- MS08-without base plate
704.79 zł
Tax included
The AD-WOP-MS08 model delivers MS08 system functionality in a base-plate-free design. This sturdy and precisely manufactured adapter enables fast and trouble-free tool connection in harsh working environments.
| Pin diameter [mm] | Inner width [mm] |
Pin spacing* [mm] |
|
|---|---|---|---|
| MS01 | 40 | 185 | 225 |
| MS01SY | 40 | 185 | 255 |
| MS03 | 50 | 205 | 283,6 |
| MS03SY | 50 | 205 | 322 |
| MS08 | 60 | 295 | 381 |
| MS08SY | 60 | 297 | 434 |
**The image is for illustrative purposes only. The order refers to the product described in the offer.
The main components are made of the following materials and thicknesses:
| MS01 | MS01SY | MS03 | MS03SY | MS08 | MS08SY | |||||||
| Thickness | Material | Thickness | Material | Thickness | Material | Thickness | Material | Thickness | Material | Thickness | Material | |
| Side plate: | 10mm | S355 | 10mm | S355 | 12mm | S355 | 12mm | S355 | 16mm | S355 | 16mm | S355 |
The product is manufactured in accordance with applicable quality and safety standards, including:
DIN EN ISO 9013, DIN ISO 2768-mK, ISO 13920-BF, DIN EN ISO 1302, DIN ISO 13715, AWS D1.1:2020
AD-WOP-MS08
Data sheet
- Lead time
- up to 48 hours
- For the machine
- 5-6t
6-7t
7-8t
8-9t
9-10t - Adapter
- MS08
- Side plate
- 16mm S355
- Pin diameter
- 60mm
- Inner width
- 295mm
- Pin spacing
- 381mm
- Weight
- 28kg
