  • Class: 2-3 T
  • Width: 500
  • Adapter: M03
Skeleton bucket 500mm M03 class 2-3t
Skeleton bucket 500mm M03 class 2-3t
Skeleton bucket 500mm M03 class 2-3t
Skeleton bucket 500mm M03 class 2-3t
Skeleton bucket 500mm M03 class 2-3t
    Skeleton bucket 500mm M03 class 2-3t
    Skeleton bucket 500mm M03 class 2-3t
    Skeleton bucket 500mm M03 class 2-3t
    Skeleton bucket 500mm M03 class 2-3t
    Skeleton bucket 500mm M03 class 2-3t

Skeleton bucket 500mm M03 class 2-3t

2,084.85 zł Tax included
In stock Lead time up to 3 business weeks

Other models:

Width
Adapter

The LAP-ZMG2-500-M03 skeleton bucket with a working width of 500 mm is a specialist tool designed for small excavators in the 2–3 t class. It is excellent for soil screening, stone separation, and sorting bulk materials from earth on construction sites and in forestry operations. The Martin M03 adapter (compatible with SW10, CM30) ensures wide compatibility with machines equipped with this popular quick coupler system. High-quality steel and careful welding technology ensure the bucket retains its shape and working properties over a long service life.

**The image is for illustrative purposes only. The order refers to the product described in the offer.

Quantity
Add to wishlist

The product is manufactured in accordance with applicable quality and safety standards, including:

DIN EN ISO 9013, DIN ISO 2768-mK, ISO 13920-BF, DIN EN ISO 1302, DIN ISO 13715, AWS D1.1:2020

LAP-ZMG2

LAP-ZMG2-500-M03

Data sheet

Lead time
up to 3 business weeks
For the machine
2-3
Adapter
M03
Width
500
Weight without adapter
49
Capacity
69
Side/rear plate
5 S355
Side cutters
8 HB400
Ribs
8 S355
Rib spacing
40
Cutting edge
16 HB500
Top plate
5 S355
Bend plate
5 S355
Number of teeth
4
Type of teeth
JCB Mini
