Class: 6-9 T
Width: 400
Adapter: Without adapter

Digging bucket 400mm without adapter class 6-9t

Digging bucket 400mm without adapter class 6-9t

Name: Digging bucket 400mm without adapter class 6-9t
Brand: Kalanto
SKU: DBS-S5-V1-400-WOA
Price: 2535.03 PLN
Availability: InStock

2,535.03 zł Tax included

In stock Lead time up to 5 business days

Other models:

Width

Adapter

Parameters

The main components are made of the following materials and thicknesses:

	Thickness	Material
Front side plate:	12mm	S355
Rear side plate:	6 mm	S355
Roll sheet:	6 mm	S355
Cutting edge:	20 x 200 mm	HB400
Side cutters:	8 mm	HB400
Top plate:	12 mm	S355
Bend plate:	10 mm	S355
Rear wear strips:	5 mm	HB400
	Type
Teeth:	E25

Watch video (2)

Alternative products with a different lead time:

DBS-S5-V1-400-WOA is a professional bucket designed for heavy-duty missions. It is ideal for 6–9 ton excavators used in large-scale road construction, deep installation trenches and ground preparation for major projects.

Its reinforced structure guarantees resistance to overloads and long, trouble-free service life.

**The image is for illustrative purposes only. The order refers to the product described in the offer.

Description
Product Details

The product is manufactured in accordance with applicable quality and safety standards, including:

DIN EN ISO 9013, DIN ISO 2768-mK, ISO 13920-BF, DIN EN ISO 1302, DIN ISO 13715, AWS D1.1:2020

Reference DBS-S5-V1-400-WOA

Data sheet

Lead time: up to 5 business days
For the machine: 6-7
7-8
8-9
Adapter: Without adapter
Width: 400
Weight without adapter: 100
Capacity: 115
Side/rear plate: 6 S355
Front side plate: 12 S355
Side cutters: 8 HB400
Roll sheet: 6 S355
Rear wear strips: 5 HB400
Cutting edge: 20x200 HB400
Top plate: 12 S355
Bend plate: 10 S355
Number of teeth: 3
Type of teeth: E25

Specific References

EAN13: 5908159221527

Watch the videos

16 other products in the same category:

Class: 2-3 T
Width: 700
Adapter: Without adapter

ZMG

Digging bucket 700mm without adapter class 2-3t

1,740.45 zł

In stock

Model LK-ZMG2-700-WOA is a professional 700 mm digging bucket intended for small excavators in the 2–3 t class. It excels in excavation work, soil removal, trenching, and all types of civil...

Class: 4-6 T
Width: 700
Adapter: CW10

ZMG

Digging bucket 700mm CW10 class 4-6t

3,453.84 zł

In stock

The LK-ZMG3-700-CW10 series is a 700 mm digging bucket dedicated to medium-class excavators of 4–6 t. Its optimal working width enables efficient foundation work, linear trenching, road...

Class: 8-11 T
Width: 1100
Adapter: S45

ZMG

Digging bucket 1100mm S45 class 8-11t

6,226.26 zł

In stock

Model LK-ZMG5-1100-S45 is a professional 1100 mm digging bucket intended for heavy excavators in the 8–11 t class. It excels in excavation work, soil removal, trenching, and all types of civil...

Class: 0-2 T
Width: 250
Adapter: MS01

ZMG

Digging bucket 250mm MS01 class 0-2t

836.40 zł

In stock

The LK-ZMG1-250-MS01 is a 250 mm digging bucket created to meet the demands of mini and compact excavators up to 2 t. It performs well in earthmoving, excavation, grading, and breaking through...

Class: 8-11 T
Width: 1000
Adapter: MS08

ZMG

Digging bucket 1000mm MS08 class 8-11t

5,902.77 zł

In stock

The LK-ZMG5-1000-MS08 series is a 1000 mm digging bucket dedicated to heavy excavators in the 8–11 t class. Its optimal working width enables efficient foundation work, linear trenching, road...

Class: 2-3 T
Width: 400
Adapter: S40

Kalanto

Digging bucket 400mm S40 class 2-3t

1,453.86 zł

In stock

This digging bucket is intended for compact excavators operating in the 2–3 ton range. DBS-S2-V1-400-S40 ensures reliable performance in foundation excavation, trenching and general building...

Class: 2-3 T
Width: 550
Adapter: Without adapter

ZMG

Digging bucket 550mm without adapter class 2-3t

1,471.08 zł

In stock

Model LK-ZMG2-550-WOA is a professional 550 mm digging bucket intended for small excavators in the 2–3 t class. It excels in excavation work, soil removal, trenching, and all types of civil...

Class: 6-9 T
Width: 500
Adapter: MS08SY

Solid Hitch

Digging bucket 500mm MS08SY class 6-9t

7,917.63 zł

Made to order

6–9 t buckets designed for quick couplers offer increased durability thanks to HARDOX 500 TUF, while CAT J teeth ensure stable and effective performance in tough terrain. **The image is for...

Class: 2-3 T
Width: 800
Adapter: MS03SY

Kalanto

Digging bucket 800mm MS03SY class 2-3t

2,206.62 zł

In stock

The DBS-S2-V1-800-MS03SY model serves as a universal digging solution for compact excavators. It handles foundation excavations, installation trenches and overall construction work with...

Class: 0-2 T
Width: 200
Adapter: with pins

ZMG

Digging bucket 200mm with pins class 0-2t

968.01 zł

In stock

The LK-ZMG1-200-ZSW digging bucket, 200 mm wide, was developed specifically for mini and compact excavators up to 2 t. Its design allows efficient foundation trenching, earthmoving, and...

Class: 3-4 T
Width: 900
Adapter: M03

ZMG

Digging bucket 900mm M03 class 3-4t

3,253.35 zł

In stock

Model LK-ZMG2-5-900-M03 is a professional 900 mm digging bucket intended for excavators in the 3–4 t class. It excels in excavation work, soil removal, trenching, and all types of civil...

Class: 2-3 T
Width: 500
Adapter: with pins

ZMG

Digging bucket 500mm with pins class 2-3t

1,926.18 zł

In stock

The LK-ZMG2-500-ZSW digging bucket with a working width of 500 mm is a sturdy tool designed for small excavators in the 2–3 t class. It is perfectly suited for foundation excavation, earthmoving,...

Class: 2-3 T
Width: 450
Adapter: S40

ZMG

Digging bucket 450mm S40 class 2-3t

1,645.74 zł

In stock

The LK-ZMG2-450-S40 digging bucket with a working width of 450 mm is a sturdy tool designed for small excavators in the 2–3 t class. It is perfectly suited for foundation excavation, earthmoving,...

Class: 0-2 T
Width: 200
Adapter: S30/180

ZMG

Digging bucket 200mm S30/180 class 0-2t

783.51 zł

In stock

Model LK-ZMG1-200-S30/180 is a professional 200 mm digging bucket intended for mini and compact excavators up to 2 t. It excels in excavation work, soil removal, trenching, and all types of civil...

Class: 4-6 T
Width: 800
Adapter: M10

Kalanto

Digging bucket 800mm M10 class 4-6t

3,377.58 zł

In stock

The DBS-S4-V1-800-M10 bucket is dedicated to medium-sized excavators working in demanding environments. Its reinforced design ensures excellent resistance to heavy loads, making it ideal for...

Class: 0-2 T
Width: 550
Adapter: S30/180

ZMG

Digging bucket 550mm S30/180 class 0-2t

1,328.40 zł

In stock

The LK-ZMG1-550-S30/180 digging bucket, 550 mm wide, was developed specifically for mini and compact excavators up to 2 t. Its design allows efficient foundation trenching, earthmoving, and...

Why KALANTO?

Fast shipping Most products are in stock and ready to ship.
Delivery across Europe We handle orders well beyond Poland.
Secure payments Encrypted online payments (Przelewy24, Stripe), card or bank transfer.
Built to last Attachments engineered for heavy, everyday work.
1250+ products in our range Trusted manufacturers in one place — and the range keeps growing.
A growing customer base Every day more construction companies choose KALANTO for their repeat orders.

Width [mm]	Weight* [kg]	Capacity [l]	Teeth [pcs]
300	89	78	3
400	100	115	3
500	116	154	4
600	131	193	4
800	164	274	5
1000	195	356	5
